Cafeterias
Light Level: 30 Foot-Candles Average / Average-to-Minimum ratio of less than 2.5FC
Lighting Power Density: 0.53 Watts/Sq. FT
Light Level: 30 Foot-Candles Average / Average-to-Minimum ratio of less than 2.5FC
Lighting Power Density: 0.63 Watts/Sq. FT
General Note: Food serving areas are required to me 40 foot-candles on average with and are allowed 0.92 Watts/Sq. FT for the examples below I have excluded serving areas as the dimensions and placement vary too much from school to school to give a fair typical. I’m confident we can raise the light output on any of the fixtures below to meeting food service requirements.
RND Series
Available in (3) Diameters - 2’, 3’, 4’
Recessed, Surface and Pendant mounting available.
Flat, Convex or Concave lensing options
Variable Light Outputs and power levels to design criteria
The calculations below were developed using cafeteria dimensions from a recent school project. The layouts use only one diameter/output, in a more complex design these could be mixed per aesthetic design requirements.
RND 2ft Diameter
RND 3ft
RND 4ft
V50 Series
1x4, 2x2 and 2x4 Vandal resistant troffer
Recessed or Surface Mounted
Customizable Lumen Packages
Ideal for Multi-Purpose Cafeteria spaces where games/sports are common.
Typical SCA Part Numbers:
V50-G-S-22-L58/835-F-VLF-DIM-UNV (2X2)
V50-G-S-24-L56/835-VLF-DIM-UNV (2X4)
V50 Series in recessed 2x2
V50 Series in recessed 2x4
VDIL
Direct/Indirect Recessed troffer with transparent vandal-resistant lens mounted in door frame.
Soft Acrylic Lens reduces glare for quieter ceiling
Typical SCA Part Numbers:
VDIL-G-S-22-L31/835-F-AD-DIM-UNV (2X2)
VDIL-G-S-24-L45/835-F-AD-DIM-UNV (2X4)
VDIL 2X2 calculation
VDIL 2x4 Calculation
HE Williams of course has many more options available in both recessed and surface mounted styles. The calculations and suggestions above are just the starting point. For project-specific suggestions and calculations, just email me.
