Bathrooms and Locker Rooms
SCA Standards: 20 Foot-Candles Average at 30” with a Lighting Power Density of 0.75 W/ Sq. Foot
SCA Standards: 20 Foot-Candles Average at 18” with a Lighting Power Density of 0.45 W/Sq. Foot
Bathrooms and locker rooms are generally lit with 2x4 recessed troffers which require occupancy sensors. This presents a unique challenge for a fixture design. In bathrooms, we can easily integrate an occupancy sensor, however, there have been concerns that occupancy sensors can be confused with cameras in the bathroom. Here are some options for bathroom and locker room lighting.
50 Series
Available in standard and in a vandal resistant (V50 model)
Wet Location is available with both models.
Occupancy Sensor Solution
Leviton OSM3D-DDW
Microwave sensor embedded above the lens of the fixture. It will not be seen by the occupants but will provide occupancy sensing and direct fixture control.
This option is factory installed.
Available for both 50 series and V50 models.
Option Code: OSM3D-DDW
Typical 50 Series Specification
For typical Bathrooms, not requiring a vandal-resistant option.
50-G-S24-L33-835-S-AF19156-(L25)-(LEVITON OSM-3D-DDW)-DIM-UNV
Typical V50 Series Specification
For Locker Rooms or bathrooms requiring a vandal resistant solution.
V50-G-S24—L31-835-F-VLF-(LEVITON OSM-3D-DDW)-DIM-UNV
The specifications and suggestions are based on previous SCA projects, for project calculations and specification information, just email me.
